Specifications

 Specifications for the Phoenix Waveform Direct Current Neurothapy Device

Technical details, output capabilities, and performance standards for all Phoenix Waveform devices.

Both the Phoenix Pro and Phoenix Elite are FDA-certified devices and include:

• Full training course

• Unlimited support directly with Dr. Jeff Banas

• Access to online training and ongoing updates

---

Elite vs. Pro — What’s the Difference?

Phoenix Elite — Includes the Phoenix Plus Program

The Elite has one additional program called Phoenix Plus, which is stronger than the standard Phoenix Hunt program.
Phoenix Plus runs at 500 Hz with a 500 µs positive pulse width and 500 µs negative pulse width, providing a deeper, more powerful neurological effect.

All other Phoenix programs operate at 300 µs positive and 300 µs negative pulse width, making Phoenix Plus the strongest program available.

---

Size & Functionality Differences

Phoenix Pro – Compact & Mobile

The Pro is about the size of a large cell phone.
It’s extremely portable, allowing you to train or rehab anywhere:

• Weight training

• Running

• Skiing

• Skating

• Cycling

• Rehab exercises

• Mobility work

You can literally put the Pro in your pocket and move freely.

Phoenix Elite – Larger Battery & More Power Options

The Elite is approximately 4× larger than the Pro and includes two large internal batteries.
Benefits of the Elite:

• Much larger battery capacity

• Ideal for longer, high-output sessions

• Includes Phoenix Plus

Both units can run on battery power or while plugged into the wall.

---

Performance Compared to ARPwave & Therastim

If you’ve used Therastim or ARPwave at high intensities, the Phoenix Elite will feel more familiar because of its strength and battery endurance.

ARPwave and Therastim use sine wave stimulation, which is a crude waveform requiring much higher intensities. This is why users often feel strong “pins and needles.”

The Phoenix devices use a clean square-wave direct current, which is:

• More powerful

• More efficient

• More comfortable

• Able to activate nerves and muscles at lower intensities

Square waves deliver more effect per unit of intensity than sine waves — “more bang for your buck.”
This is why Phoenix devices can produce deeper results without cranking the intensity to painful levels.

---

Pricing Summary

• Phoenix Elite — $4,100

  • 4× larger unit

  • Larger battery

  • Includes Phoenix Plus program

• Phoenix Pro — $3,500

  • Smaller, compact, portable

  • Same core Phoenix programs

  • Does not include Phoenix Plus

Both units deliver identical Phoenix current through two channels (1 and 3), allowing for four pads.
If you want to expand to more pads, simply use a splitter to turn one lead into two — giving you up to 8 pads.
Many protocols work well with 3 leads (one split, one not).

---

Training Resources

I’m always adding training videos here:
YouTube Channel:
https://www.youtube.com/channel/UCZhY9UdQyHdRlu4RxL3cDHw?view_as=subscriber

If you don’t find what you need on PhoenixWaveform.com or YouTube, let me know and I’ll create a video specifically for your questions.

Online training course (included with purchase):

Thinkific Online Course:
https://jeff-s-school-7751.thinkific.com

---

Prescription Requirement

If you are not a chiropractor, physical therapist, athletic trainer, or healthcare provider, a prescription is required for purchasing an electrical muscle stimulation device.

A simple email or signed script from any provider (DC, PT, MD, DO, NP, etc.) is sufficient.

---

Unlimited Support Included

Every Phoenix purchase comes with unlimited direct support from me.
You can call or message anytime with questions about:

• Protocols

• Settings

• Pad placement

• Patient setup

• At-home programs

• Athletic performance use

I’m here to help you succeed.

---

Phoenix Elite Edition

Phoenix Elite – Program list

• Phoenix Wave (Tweaked to have a DC component)

  • • Hunt: 500 Hz, pulse-width 300 positive and 300 µs negative.(Used for hunting for trigger points)

    • Phoenix Plus: 500 Hz, 500 µs of pulse-width positive, and 500 µs negative.

    • 300 Phoenix Wave: 300Hz pulse-width 300 positive and 300 µs negative.

    • 165 Phoenix Wave: 165Hz pulse-width 300 positive and 300 µs negative.

    • 135 Phoenix Wave: 135Hz pulse-width 300 positive and 300 µs negative.

    • 40 Phoenix Wave: 40 Hz pulse-width 300 positive and 300 µs negative.

    • 10 Phoenix Wave: 10 Hz pulse-width 300 positive and 300 µs negative.

    • 500 Hz – 200 µs

    • Zero: The main current remove background DC current running. For when you want neuro-stimulation without muscle contraction.

    • Nap: Main current at 1HZ, background DC current running. For when you want neuro-stimulation without muscle contraction.

    • Square Sleep

    • E.C.O. (Endorphin, Circulation, Oxygenation)

                          Cycling from 12-8 Hz in 30 sec and back for the first 6 minutes; then cycling from 8-4 Hz in

                               30 sec and back for the next 6 minutes. Square Wave.

                            40 Hz

• • • Square 255 Hz 300 µs

    • Square 135 Hz 300 µs

    • Square 255 Hz 450 µs

    • 8 HR Sleep: Main current at 1HZ, background DC current running. For when you want neuro-stimulation without muscle contraction

TENS

(Pain Control)

Electrotherapy

-KOTZ (Russian Stimulation)

-NEMS Programs

Interferential

(Pain, edema)

Microcurrents – conditions

Microcurrent stimulation to the body causes radically increased production of ATP levels. This allows the body to perform whatever healing process it has undertaken in an accelerated fashion. It may even allow one to get over the proverbial “hump” that was unachievable, due to insufficient ATP concentrations to perform the changes needed.

Microcurrent G-Pulse (Fascial)

The G Pulse treatments increase circulation and give the necessary energy to sustain cellular metabolism and protein synthesis of skin cells.

Rehabilitation

Condition-specific programs for injury rehabilitation

Fitness-Physical Shape

Specific programs to body shape and fitness

Phoenix Professional Program List

• Phoenix Wave (Tweaked to have a DC component)

  • • Hunt: 500 Hz, pulse-width 300 positive and 300 µs negative.(Used for hunting for trigger points)

    • 300 Phoenix Wave: 300Hz pulse-width 300 positive and 300 µs negative.

    • 165 Phoenix Wave: 165Hz pulse-width 300 positive and 300 µs negative.

    • 135 Phoenix Wave: 135Hz pulse-width 300 positive and 300 µs negative.

    • 40 Phoenix Wave: 40 Hz pulse-width 300 positive and 300 µs negative.

    • 10 Phoenix Wave: 10 Hz pulse-width 300 positive and 300 µs negative.

    • 500 Hz – 200 µs

    • Zero: The main current is removed and the background DC current running. For when you want neuro-stimulation without muscle contraction.

    • Nap: Main current at 1HZ, background DC current running. For when you want neuro-stimulation without muscle contraction.

    • Square Sleep

    • E.C.O. (Endorphin, Circulation, Oxygenation)

                                  Cycling from 12-8 Hz in 30 sec and back for the first 6 minutes; then cycling from 8-4 Hz                                     in 30 sec and back for the next 6 minutes. Square Wave.

• • • 40 Hz

    • Square 255 Hz 300 µs

    • Square 135 Hz 300 µs

    • Square 255 Hz 450 µs

    • 8 HR Sleep: Main current at 1HZ, background DC like current running. For when you want neuro-stimulation without muscle contraction

TENS

(Pain Control)

Electrotherapy

-KOTZ (Russian Stimulation)

-NEMS Programs

Interferential

(Pain, edema)

Microcurrents – conditions

Microcurrent stimulation to the body causes radically increased production of ATP levels. This allows the body to perform whatever healing process it has undertaken in an accelerated fashion. It may even allow one to get over the proverbial “hump” that was unachieveable, due to insufficient ATP concentrations to perform the changes needed.

Microcurrent G-Pulse (Fascial)
